Dual-Axis Electric Turntable DET-450A

Name: Dual-Axis Electric Turntable DET-450A
Brand: OELABS
SKU: DET-450A
Availability: InStock
Rating: 5 (1 reviews)

No.DET-450A

DET-450A dual-axis motorized rotary table has two degrees of freedom of motion, azimuth (X) and pitch (Y) axes, and is a table-type two-dimensional precision test equipment. It is mainly used for the experimental test of position, rate, swing and other functions of precision components and assemblies.

GET A QUOTE Download

Description
Contact Us
Download

Technical specification

Rated load: 30Kg
Table size: Ф450mm
Table flatness: 0.02mm;
Table jump: 0.02mm;
Dual-axis rotary accuracy: ±3”;
Dual-axis positional accuracy: outer frame: ±3″, inner frame: ±3″
Perpendicularity of inner and outer ring axes: ±5″
Rate resolution: better than 0.001°/s
Rate accuracy and smoothness

ω≤1°/s , 2×10^-3 (1° averaging method);

1°/s ≤ ω<10°/s , 2×10^-4 (10° averaging method);

ω ≥10°/s , 2×10^-5 (360° averaging).

Rate range

Inner frame: ±0.001°/s to ±800°/s;

Outer frame: ±0.001°/s～±300°/s.

11. Acceleration

Outer frame: greater than 100°/s²;

Inner frame: more than 200°/s².

Table body weight: ≤750Kg
External dimension of the table body: 1320×700×960
