Product Properties
LED curing , low modulus, good elongation
Storage Conditions
KG coatings is available in 10kg or 1000kg plastic bottle which prevent exposure of the content to UV light. It is recommended that KG coatings be stored in a dry place in unopened, undamaged, original containers at temperatures between 0°C and 35°C. Storage or shipment in cold conditions may result in a phase separation which is reversible and is corrected by heating for 24 hours at 40°C .
Shelf Life
KGOE190-4 has a recommended shelf life of 12 months from the date of manufacture, provided that the above stated storage conditions are properly maintained.
Characteristics
|
Liquid Coating |
Typical Value |
|
Viscosity（25°C） |
5400cps |
|
Refractive Index（23°C） |
1.473 |
|
Density (23°C) |
1.05kg/l |
|
Cured Film |
Typical Value |
|
By DMA Temperature when E'=1000Mpa |
-55.4°C |
|
Temperature when E'=100Mpa |
-47.2°C |
|
Modulus at 2.5% strain |
1.06MPa |
|
Elongation |
100% |
|
Tensile strength |
0.50MPa |
|
Curing speed (at 95% of relative curing degree) |
0.25J/cm2 |
|
Shrinkage upon curing |
2.7% |
|
Refractive Index（23°C） |
1.477 |
|
Weight loss 8 weeks at 85°C |
-4.3% |
|
8 weeks at 125°C |
-5.7% |
|
Adhesion to glass（23°C） |
0.9N |
